McHale F5600 Heavy Fixed Chamber Baler

At the higher end of the McHale F5000 fixed chamber round baler range is the McHale F5600 fully automatic round baler, this is the highest specification round baler in the McHale F5000 round baler range.

The McHale F5600 is fitted with a servo operated load sensing control valve and an expert plus control console, which makes the round baling process fully automatic.

Once the round bale is formed, net is automatically applied; the tailgate then automatically opens releasing the high density round bale, the tailgate on the F5600 baler then automatically closes and pressurises.

The F5600 fully automatic round baler comes standard with all the high specification features of the F5500 round baler but also benefits from;

  • An Expert Plus control console with a large graphic display
  • A high capacity 25 knife totor (optional)
  • Automatic tailgate operation
  • Drop floor nnblocking cycle
  • Bale kicker sensor
  • In-cab net adjustment
  • In-cab bale density adjustment


Specifications

Dimensions & Weight



Width

2.58m

Length

4.05m

Weight

3700kg

Height

2.45m

Pick Up



Pick Up Lift

Hydraulic

Crop Roller

Optional

Short Crop Guard

Standard

Tine Spacing

70mm

Tine Bars

5

Working Width

2100mm

Pick Up Guide Wheels

Standard

Chopper Unit



Unblocking System

Drop Floor

Knife Deactivation

Hydraulic from Cab

Knife Protection

Hydraulic

Theoretical Chop Length

46mm

Number of Knives

25

Bale Chamber



Width(m)

1.23

Diameter(m)

1.25

Greasing

Automatic Progressive

Bearings

50mm

Number of Rollers

18

Bale Chamber Feed

Fusion Rotor

Net  Wrap



Net Adjustment

In Cab

Net Roll Capacity

1+1 Storage

Net System

Vario Stretch

Control

Manual or Automatic

Drives



Chain Lubrication

Continuous

Pick Up Protection

Slip Clutch

Main Drive Protection

Cam Clutch

Gearbox

Split Drive

Control



Density Adjustment

In Cab

Operation

Automatic

Control System

Expert  Plus

Other



Axle

8 Stud

Road Lights

Standard

Bale Kicker Indicator

Standard

Tyres Standard

500/50-22.5

Tractor



**Bearings are double on the main load points



Hydraulics

2 double acting spools

Minimum Power Requirements

75kW (100hp)
